testo 770-1 - Clamp meter
Price RM612.00 RM733.62
Product SKU 0590 7701
Brand Testo
Size (L x W x H) 36 cm x 16 cm x 6 cm
Availability In Stock
Shipping Fee
Quantity
Description
Highlight
  • Fully retractable pincer arm for maximum flexibility
  • Auto AC/DC
  • Large two-line display
  • Measures the common electrical parameters

Description

Product Description

This clamp meter means you can cope in any application environment, no matter how tight. The movable pincer arm can be fully retracted into the instrument, so that you can for instance grab tightly packed cables in switching cabinets as if you were using a hook. You have never been able to measure as conveniently as this in tight spots.

The operation of the testo 770-1 clamp meter is also easier and more reliable than ever before. It automatically detects and selects AC/DC and other electrical parameters, such as resistance, continuity, diode and capacitance. In addition, you can also use it to measure the starting current. And the two-line display presents your readings clearly and distinctly.



Delivery Scope

testo 770-1 TRMS clamp meter, including battery, 1 set of measuring cables (0590 0010), calibration protocol and instruction manual.



Specification

DC voltage

Measuring range

1.0 to 600.0 V

Resolution

max. 1 mV

Accuracy

± (0.8 % of mv + 3 Digit)

AC voltage

Measuring range

1.0 mV to 600.0 V

Resolution

max. 1 mV

Accuracy

± (1.0 % of mv + 3 Digit)

DC current

Measuring range

0.1 to 400 A

Resolution

max. 0.1

Accuracy

± (2 % of mv + 5 Digit)

AC current

Measuring range

0.1 to 400 A

Resolution

max. 0.1 A

Accuracy

± (2 % of mv + 5 Digit)

Resistance

Resolution

max. 0.1 Ohm

Measuring range

0.1 to 40.00 MOhm

Accuracy

± (1.5 % of mv + 3 Digit)

Capacitance

Resolution

max. 0.01 nF

Measuring range

10 nF to 100.0 μF

Accuracy

± (1.5 % of mv + 5 Digit)

Frequency

Measuring range

10 nF to 100.0 μF

Accuracy

±(0.1 % + 1 Digit)



Applications

Ideal for non-contact current measurement on tightly packed cables

  • Fully retractable pincer arm, auto AC/DC, large two-line display, true root mean square (TRMS) measurement, starting current measurement

Overview of applications

  • Current consumption measurement, testing voltage supply in live wires, measuring the ionization flow of heating systems, continuity tests on switching components, resistance measurement of sensors or motor windings




Download

Product Brochure



  ​  Data sheet testo 770  (PDF, 234 KB)



Reviews (0)
view all
back
0
0 reviews
What's in the box

testo 770-1 TRMS clamp meter, including battery, 1 set of measuring cables (0590 0010), calibration protocol and instruction manual.
